Product Details
Place of Origin: China
Brand Name: Vic-Tech
Certification: RoHS
Model Number: SM25-048S
Payment & Shipping Terms
Minimum Order Quantity: 1Unit
Price: $4~$8/Unit
Packaging Details: Samples are packed with paper box, and mass production products are packed with standard corrugated carton.
Delivery Time: 10~20 days after the sample is paid
Payment Terms: T/T, Paypal, Credit card
Supply Ability: 100000 pc/Month
Motor Type: |
PM Stepper Motor With Gearbox |
Motor Diameter: |
25mm |
Resistance: |
20Ω±10%（25℃） |
Step Angle: |
7.5°/gear Ratio |
Phase No.: |
2 |
Current: |
400mA/phase |
Voltage: |
12V DC |
Max Pull-in Rate: |
700PPS |
Motor Type: |
PM Stepper Motor With Gearbox |
Motor Diameter: |
25mm |
Resistance: |
20Ω±10%（25℃） |
Step Angle: |
7.5°/gear Ratio |
Phase No.: |
2 |
Current: |
400mA/phase |
Voltage: |
12V DC |
Max Pull-in Rate: |
700PPS |
Chinese factory D shaft 25mm diameter micro bipolar stepper motor with gearbox
This motor is a 25mm permanent magnet permanent magnet stepper motor with gearbox,
The step angle of a single motor is 7.5 degrees (without gearbox), and the speed and output torque of the motor are also different for different transmission ratios. Our speed ratios are: 30:1, 20:1, 15:1,
The larger the gear ratio of the gearbox, the slower the output speed and the greater the output torque.
The gear ratio is selected according to the torque/speed required by the customer.
Stepper motors are widely used in all walks of life.
| Motor type | PM stepper motor + gearbox |
| Motor size | 25mm diameter |
| Phase number | 2 Phase |
| Driving method | 2-2 bipolar driving |
| Step angle | 7.5°/gear ratio |
| Current | 600 mA/phase |
| Voltage | 6~12 V DC |
| Coil resistance | 20Ω/phase |
Stepper motors are used for precise control, widely used on medical equipment, 3D printer, industrial precise control, automation equipment, etc.
Stepper motors can be used in any mechanisms requirement precise conrtol and rotational/linear movement.
Stepper motors can achieve precise control even without a closed loop encoder/feedback system, and without brushes. Therefore, there is no electromagnetic interference and electric spark problems in stepper motors. Stepper Motors In some cases, they can replace DC brushed/brushless motors.
The stepper motor is easy to control by the driver, which has established its important position in the field of precision control.
1. Precise control achievable, programmable
2. Without electromagnetic interference & electrical sparks
3. Small size
4. Reasonable price
5. Low noise
6. Long service life
